What It Does
The ez Share Wi-Fi SD card adapter creates its own isolated Wi-Fi access point inside whatever device it's plugged into. Your home network has no visibility into it.
The Mule & Miner sits on your network, connects to that ez Share AP, and forwards the data over your LAN via HTTP or MQTT — on a configurable polling interval. Plug it in, provision it once via captive portal, and it runs headlessly from then on.
Specifications
| Microcontrollers | 2× ESP32-C3 (RISC-V, 160 MHz) |
| Wi-Fi | 2× independent 2.4 GHz 802.11 b/g/n |
| Power | USB-C, 5V / ~250 mA typical |
| Output | HTTP (REST) · MQTT |
| Provisioning | Captive portal (no serial cable needed) |
| Enclosure | 3D-printed PLA+, white |
| Dimensions | ~XX × XX × XX mm |
In the Box
✓Mule & Miner — assembled & tested
✓USB-C power cable
✓Quick-start card
✗USB power adapter — not included
Known Applications
CPAP Therapy Monitoring
ResMed machines (AirSense 10/11, AirCurve 10) or any other model that writes session data to the SD card. The Mule & Miner makes that data available on your network in real time while you sleep.
Camera / Dashcam SD Offload
Any camera using an ez Share adapter can have its files automatically forwarded to a NAS or local server without removing the card.
General ez Share Network Bridge
Any device with an ez Share SD card inserted becomes network-accessible. What you do with the data is up to you.
